Product Detail Information
Attribute Name	Attribute Data
Active Area	246.0 x 184.5 mm
Backlight System	2 x CCFT
Brightness	450 nits
Contrast Ratio	600:1
Description	LCD Displays
Diagonal Size	12.1 inch (31.0 cm)
Display Mode	Normally White
Family	LQ121S1LG61
Interface	LVDS: 262,144 colors
Operating Temperature Range	-30°C to 80°C
Outline Dimensions	276.0 x 209.0 x 11.0 mm
Pixel Format	800 x 600
Response Time	35 ms
RoHS	Yes
Status	Production
Storage Temperature Range	-30°C to 80°C
Type	SVGA Strong 2
Viewing Angle - 12 o clock	50 °
Viewing Angle - 6 o clock	60 °
Viewing Angle - side to side	140 °
